We Solve Problems for the Electronic Industry

Failure analysis, electrical testing, process evaluation and testing to many specifications.

Start solving
microscope

Recent Success Stories

Avago Optocoupler HCPL-2202 Failure Analysis

Avago Optocoupler HCPL-2202 Failure Analysis

Gideon Analytical Laboratories received several Avago HCPL-2202 Optocouplers for failure analysis. These optocouplers have a totem pole output stages and optical receiver input stages with built-in Schmitt triggers to provide logic-compatible waveforms. They feature low input current (1.6mA to 1.8mA), Mbd typical signal rate, and guaranteed performance from -40 to 85 degrees Celsius. Some of their applications include isolation of high-speed logic systems, microprocessor system interfaces, and ground loop elimination. Our goal was to determine why the Avago HCPL-2202 Octocouplers had been failing.
Failed Cortina WJLXT971ALCA4e3 IC on PCB

Failed Cortina WJLXT971ALCA4e3 IC on PCB

Gideon Analytical Laboratories received 20 failed Cortina WJLXT971ALCA4e3 Ethernet ICs to analyze. Integrated Circuits (ICs) are a set of electronic circuits on one small flat piece (or “chip”) of semiconductor material that is normally silicon. The integration of large numbers of tiny transistors into a small chip results in circuits that are orders of magnitude smaller, faster, and less expensive than those constructed of discrete electronic components. These Cortina WJLXT971ALCA4e3 ICs were suspected to be possibly mislabeled or have some kind of manufacturing defects.
Failure Analysis of TI TPS767D301 Voltage Regulator

Failure Analysis of TI TPS767D301 Voltage Regulator

Gideon Analytical Laboratories received one TI TPS767D301 dual-output low-dropout voltage regulator with a ground to reset short The TI TPS767D301 offers a transient response, low dropout voltages, and dual outputs. It is designed primarily for DSP applications. It features extended temperature performance from 55 to 125 degrees Celsius, drop out voltage typically 350 mV at 1 A, and enhanced product-change notification. The goal was to determine why these TI TPS767D301 voltage regulators were failing, paying special attention to the ground to reset short.
Failure Analysis on RY4S-UAC110-120V Power Relay

Failure Analysis on RY4S-UAC110-120V Power Relay

Gideon Analytical Laboratories received several RY4S-UAC110-120V power relays for failure analysis. A relay is an electrically operated switch. Many relays use an electromagnet to operate the switch, but other operating principles are also used, such as solid-state relays. Relays are used where it is necessary to control a circuit by a separate low-power signal, or where several circuits must be controlled by one signal. Relays are used to control a high power or high voltage circuit with a low power circuit.
Failure Analysis on T491D475K050AT Kemet Tantalum Capacitor

Failure Analysis on T491D475K050AT Kemet Tantalum Capacitor

Gideon Analytical Laboratories received several T491D475K050AT Kemet tantalum capacitors for electronic failure analysis. A capacitor is a passive two-terminal electronic component that stores electrical energy in an electric field. While some capacitance exists between any two electrical conductors in proximity in a circuit, a capacitor is a component designed to add capacitance to a circuit. The Kemet T491D475K050AT has a capacitance of 4.7 uF, a voltage rating of 50 VDC, and a tolerance of 10%, measures 7.
Failure Analysis on TI TMS320F28335PGFA DSP

Failure Analysis on TI TMS320F28335PGFA DSP

Gideon Analytical Laboratories received a TI TMS320F28335PGFA Digital Signal Processor for failure analysis. Digital Signal Processing applications include audio and speech processing,sonar,radar, and other sensor array processing,spectral density estimation,statistical signal processing,digital image processing, among many others. The TI TMS320F28335PGFA features high-performance static CMOS technology, a 32-bit CPU, 16 x 16 and 32 x 32 MAC operations, and Harvard bus architecture. It has up to 88 individually programmable, multiplexed GPIO pins with input filtering.
Stackpole 100-ohm Power Resister Failure Analysis

Stackpole 100-ohm Power Resister Failure Analysis

Gideon Analytical Laboratories received three different vendor 100-ohm resistors, made by Vishay, RCD, and Stackpole, respectively. The two Stackpole resistors were open. A resistoris a passive two-terminal electrical component that implements electrical resistance as a circuit element. In electronic circuits, resistors are used to reduce current flow, adjust signal levels, to divide voltages, bias active elements, and terminate transmission lines, among other uses. Our goal was to test the functionality the Vishay, RCD, and Stackpole resistors, and if any were failing, determine the cause of the failure.
Failure Analysis on 1N645 Silicon Rectifier Diodes

Failure Analysis on 1N645 Silicon Rectifier Diodes

Gideon Analytical Laboratories received two 1N645 silicon rectifier diodes for failure analysis. One was bad and the other was a quality diode to be used for comparison. A rectifier is an electrical device that converts alternating current(AC), which periodically reverses direction, to direct current(DC), which flows in only one direction. Rectifiers are used inside the power supplies of virtually all electronic equipment. AC/DC power supplies may be broadly divided into linear power supplies ands witched-mode power supplies.
Failure Analysis on Murata Electronics GCM21BR70J106KE22L MLCCs

Failure Analysis on Murata Electronics GCM21BR70J106KE22L MLCCs

Gideon Analytical Laboratories received several Murata Electronics GCM21BR70J106KE22L Multi-Layered Ceramic Capacitors (MLCCs) for failure analysis. An MLCC consists of a number of individual capacitors stacked together in parallel and contacted via the terminal surfaces. The starting material for all MLCC chips is a mixture of finely ground granules of paraelectric or ferroelectric raw materials, modified by accurately determined additives. The Murata Electronics GCM21BR70J106KE22L has a capacitance of 10 uF, a DC voltage rating of 6.
Failure Analysis on Sunon Maglev MC35101V2-000U-G99 12V fans

Failure Analysis on Sunon Maglev MC35101V2-000U-G99 12V fans

Gideon Analytical Laboratories received two Sunon Maglev MC35101V2-000U-G99 12V fans which did not operate. Along with the nonoperational fans, two functional fans were also sent to us for comparison. The Sunon Maglev MC35101V2-000U-G99 12V fan is an axial DC fan, with a speed of 7500 RPM and airflow of 6.5 CFM. An axial fan is a type of fan that causes gas to flow through it in an axial direction, parallel to the shaft about which the blades rotate.
Read more Success Stories

How It Works

step one graphic

Provide Gideon Labs with information about your failure

step two graphic

We use a variety of industry techniques to diagnose the failure

step three graphic

You get a comprehensive report of why the failure occurred
